IPC HERMES-9852 PDF

$95.00

The Global Standard for Machine-to-Machine Communication in SMT Assembly Version 1.4

Published by Publication Date Number of Pages
IPC 02/01/2022 64
PDF FormatPDF FormatMulti-User-AccessMulti-User AccessPrintablePrintableOnline downloadOnline Download
Category:

Description

IPC HERMES-9852 – The Global Standard for Machine-to-Machine Communication in SMT Assembly Version 1.4

The aim of this specification is to create a state-of-the-art communication protocol for surface-mount technology (SMT) production lines. Therefore, this new communication protocol has to cope with the following:
– Replace the electrical SMEMA interface as specified in IPC-SMEMA-9851
– Extend the interface to communicate:
Unique identifiers for the handled printed circuit boards (PCBs)
Equipment identifiers of the first machine noticing a PCB
Barcodes
Conveyor speed
Product type specific information:
Product type identifier
Length
Width
Thickness
. . .

With respect to version numbers The Hermes Standard adheres to the rules of Semantic Versioning 2.0.0 [SemVer_2.0.0].

Hints on naming:
– Wherever a feature is described by the word “shall” it is mandatory.
– The word “machine” is used for any equipment which can be found in a SMT production line (e.g., printers, placement machines, ovens, AOIs, transport modules, shuttles, stackers).
– The term “PCB” may also refer to carriers transporting PCBs.
– The word “Hermes” is used as abbreviation for “The Hermes Standard”.
– “The Hermes Standard” and IPC-HERMES-9852 are synonyms for the standard specified in this document and might be used interchangeably.





Product Details

Edition:
1.4
Published:
02/01/2022
ISBN(s):
9781638160632
Number of Pages:
64
File Size:
1 file , 3.7 MB
Product Code(s):
9852-STD-0-D-4-EN-0, 9852-STD-0-D-4-EN-0
Note:
This product is unavailable in Russia, Ukraine, Belarus
